NR3060-AQC Spindle Air driven tool change (60.000 rpm) Dia. 30mm
Product information
Spindle Air driven tool change (Max. 60.000 rpm) Diameter 30mm
| Max. rpm | 60,000 rpm |
| Air pressure to open the collet | 0.6 MPa |
| Spindle accuracy | Within 1 μm |
| Collet Retainer | QC3-K / QC3-K-R (for collet CHK) QC3-A / QC3-A-R (for collet CHA) QC3-SS (for collet CHSS) |
| Weight | 1,230 g |
| Standard accessories | Fixed Key (22 × 27): 1 pc Air hose with filter (K-251): Dia 6 mm × 2 m 1 pc |
Quick and easy change of collet holder with air-driven chuck mechanism.
Improves productivity by enabling external tooling.
3 types of collet holders are available (CHK Dia. 0.5-6.35 mm, CHA Dia. 0.5-4.0 mm, CHSS Dia. 1.0-3.175 mm)
